Ports are used in a planar structure to order and index the sources for calculation of circuit parameters such as scattering (S), impedance (Z) and admittance (Y) parameters. In EM.Cube's [[Planar Module]], you can use the following types of sources to define ports:
# * Gap Sources# * Probe Sources# * Active Lumped Elements# * De-Embedded Sources
Ports are defined in the '''Observables''' section of the Navigation Tree. Right click on the '''Port Definition''' item of the Navigation Tree and select '''Insert New Port Definition...''' from the contextual menu. The Port Definition Dialog opens up, showing the default port assignments. If you have N sources in your planar structure, then N default ports are defined, with one port assigned to each source according to their order on the Navigation Tree. Note that your project can have mixed gap and probes sources as well as active lumped element sources.
